坏死亲和性MRI对比剂Gd-DO3A-rhein的合成及其靶向性

卞丽, 高萌, 黄德健, 彭飞, 张健, 殷志琦

卞丽, 高萌, 黄德健, 彭飞, 张健, 殷志琦. 坏死亲和性MRI对比剂Gd-DO3A-rhein的合成及其靶向性[J]. 中国药科大学学报, 2017, 48(3): 282-288. DOI: 10.11665/j.issn.1000-5048.20170305
引用本文: 卞丽, 高萌, 黄德健, 彭飞, 张健, 殷志琦. 坏死亲和性MRI对比剂Gd-DO3A-rhein的合成及其靶向性[J]. 中国药科大学学报, 2017, 48(3): 282-288. DOI: 10.11665/j.issn.1000-5048.20170305
BIAN Li, GAO Meng, HUANG Dejian, PENG Fei, ZHANG Jian, YIN Zhiqi. Synthesis and necrosis target of necrosis-avid MRI contrast agent Gd-DO3A-rhein[J]. Journal of China Pharmaceutical University, 2017, 48(3): 282-288. DOI: 10.11665/j.issn.1000-5048.20170305
Citation: BIAN Li, GAO Meng, HUANG Dejian, PENG Fei, ZHANG Jian, YIN Zhiqi. Synthesis and necrosis target of necrosis-avid MRI contrast agent Gd-DO3A-rhein[J]. Journal of China Pharmaceutical University, 2017, 48(3): 282-288. DOI: 10.11665/j.issn.1000-5048.20170305

坏死亲和性MRI对比剂Gd-DO3A-rhein的合成及其靶向性

基金项目: 国家自然科学基金资助项目(No.81473120);常州四药医院药学科研基金资助项目(No.2014YX011)

Synthesis and necrosis target of necrosis-avid MRI contrast agent Gd-DO3A-rhein

  • 摘要: 以大黄酸为底物合成磁共振成像(MRI)对比剂并评价其坏死靶向性。经两步酰化和两步脱保护方法得到新的配体10-{[6-(1,8-二羟基蒽醌-3-甲酰氨基)己基]氨基}乙酰基-1,4,7,10-四氮杂环十二烷-1,4,7-三乙酸(DO3A-rhein),再与Gd3+配位得到顺磁性对比剂10-{[6-(1,8-二羟基蒽醌-3-甲酰氨基)己基]氨基}乙酰基-1,4,7,10-四氮杂环十二烷-1,4,7-三乙酸钆(Gd-DO3A-rhein)。采用大鼠再灌注肝坏死和肌肉坏死模型评价Gd-DO3A-rhein的坏死靶向性,分别在给予Gd-DO3A-rhein(0.1 mmol/kg)前和给药后0~12 h进行MRI成像,Gd-DOTA作为对照,成像结束后处死大鼠,对坏死组织进行HE和TTC染色验证坏死模型。MRI成像结果表明,在注射Gd-DO3A-rhein(0.1 mmol/kg)后3、12 h,坏死肝信号呈显著增强,坏死肝与正常肝对比度分别为1.61±0.14、2.36±0.20与给药前(1.16±0.10)呈显著性差异(P<0.05),坏死肌肉呈现同样的结果。以上结果说明,该对比剂具有良好的坏死靶向性,具有成像坏死组织的潜力。
    Abstract: The purpose of this study was to synthesize and evaluate the necrosis target of MRI contrast agent based on rhein. The novel ligand 10-{[6-(1, 8-dihydroxyanthraquinone-3-carboxamido)hexyl]amino}acetyl-1, 4, 7, 10-tetraazacyclododecan-1, 4, 7-triacetic acid(DO3A-rhein)was synthesized by two-step acylation and two-step deprotection. The paramagnetic contrast agent gadolinium 10-{[6-(1, 8-dihydroxyanthraquinone-3-carboxamido)hexyl]amino} acetyl-1, 4, 7, 10-tetraazacyclododecan-1, 4, 7-triacetate(Gd-DO3A-rhein)was obtained by coordination of Gd3+ with the synthesized ligand. Its necrosis affinity was evaluated by liver infarction and muscular necrosis on rat models. The MRI was performed before administration of Gd-DO3A-rhein and during 0 h to 12 h after administration of Gd-DO3A-rhein(0. 1 mmol/kg), respectively, and Gd-DOTA was used as control. After MRI scanning, rats were sacrificed and necrotic tissues were stained using triphenyltetrazolium chloride(TTC)and hematoxylin-eosin(HE). MRI images of liver infarction and muscular necrosis on rat models showed significantly enhanced signal intensity compared with normal tissues. The contrast ratios of necrotic liver/normal liver were 1. 61±0. 14 and 2. 36±0. 20 at 3 h and 12 h postinjection of Gd-DO3A-rhein(0. 1 mmol/kg)respectively, demonstrating a significant difference compared with pre-administration of Gd-DO3A-rhein(1. 16±0. 10; P<0. 05). The same results were obtained from necrotic muscles. These findings suggested that Gd-DO3A-rhein possessed the necrosis target and imaging capability of necrotic tissues.
  • [1] Dasari M,Lee S,Sy J,et al.Hoechst-IR:an imaging agent that detects necrotic tissue in vivo by binding extracellular DNA[J].Org Lett,2010,12(15):3300-3303.
    [2] Walker NI,Harmon BV,Gobé GC,et al.Patterns of cell death[J].Methods Achiev Exp Pathol,1988,13(13):18-54.
    [3] Park D,Xie BW,Van Beek ER,et al.Optical imaging of treatment-related tumor cell death using a heat shock protein-90 alkylator[J].Mol Pharm,2013,10(10):3882-3891.
    [4] Li JD,Zhang J,Yang SW,et al.Synthesis and preclinical evaluation of radioiodinated hypericin dicarboxylic acid as a necrosis avid agent in rat models of induced hepatic,muscular,and myocardial necroses[J].Mol Pharm,2015,13(1):232-240.
    [5] Fonge H,Vunckx K,Wang H,et al.Non-invasive detection and quantification of acute myocardial infarction in rabbits using mono-[123I] iodohypericin μSPECT[J].Eur Heart J,2008,29(2):260-269.
    [6] Feng YB,Cona MM,Vunckx K,et al.Detection and quantification of acute reperfused myocardial infarction in rabbits using DISA-SPECT/CT and 3.0 T cardiac MRI[J].Int J Cardiol,2013,168(4):4191-4198.
    [7] Fonge H,Jin LX,Wang HJ,et al.Synthesis and preliminary evaluation of mono-[123I] iodohypericin monocarboxylic acid as a necrosis avid imaging agent[J].Bioorg Med Chem Lett,2007,17(14):4001-4005.
    [8] Wang C,Jin QM,Yang SW,et al.Synthesis and evaluation of 131I-skyrin as a necrosis avid agent for potential targeted radionuclide therapy of solid tumors[J].Mol Pharm,2015,13(1):180-189.
    [9] Liu XJ,Jiang CH,Li Y,et al.Evaluation of hypericin:effect of aggregation on targeting biodistribution[J].J Pharm Sci,2015,104(1):215-222.
    [10] Wang Q,Zhang DJ,Li JD,et al.Research on the necrosis target and imaging of necrotic myocardium of 131I-emodin and 131I-emodic acid[J].J China Pharm Univ(中国药科大学学报),2016,47(2):235-241.
    [11] Wang Q,Yang SW,Jiang CH,et al.Discovery of radioiodinated monomeric anthraquinones as a novel class of necrosis avid agents for early imaging of necrotic myocardium[J].Sci Rep,2016,6:21341.
    [12] Perek N,Sabido O,Le Jeune N,et al.Could 99mTc-glucarate be used to evaluate tumour necrosis[J]?Eur J Nucl Med Mol Imaging,2008,35(7):1290-1298.
    [13] Zhang DJ, Huang DJ, Ji Y, et al. Experimental evaluation of radioiodinated sennoside B as a necrosis-avid tracer agent[J].J Drug Target,2015,23(2):180-190.
    [14] Park JA,Lee YJ,Ko IO,et al.Improved tumor-targeting MRI contrast agents:Gd(DOTA)conjugates of a cycloalkane-based RGD peptide[J].Biochem Biophys Res Commun,2014,455(3/4):246-250.
    [15] Pereira RS,Prato FS,Wisenberg G,et al.The use of Gd-DTPA as a marker of myocardial viability in reperfused acute myocardial infarction[J].Int J Cardiovasc Imaging,2001,17(5):395-404.
    [16] Ni Y,Miao Y,Bosmans H,et al.Evaluation of interstitial liver tumor ablation with gadophrin-2 enhanced MRI(abs)[J].Eur Radiol,1999,9(1):1220.
    [17] Saeed M,Bremerich J,Wendland MF,et al.Reperfused myocardial infarction as seen with use of necrosis-specific versus standard extracellular MR contrast media in rats[J].Radiology,1999,213(1):247-257.
